Paper Loading (MP)
| No. | Name |
|---|---|
| 1 | MP Tray Lifting Clutch |
| 2 | Paper Tray Assy |
| 3 | Post-Reversing Paper Feed Sensor |
| 4 | Reversal Drive Motor Encoder |
| 5 | MP Retard Roller Cover |
| 6 | MP Pickup Roller |
