Ink System Mechanism (IS)
| No. | Name |
|---|---|
| 1 | Cap Drive Motor Encoder |
| 2 | Cap Lifting Motor Assy |
| 3 | Ink System Unit |
| 4 | Cap Unit |
| 5 | Cap HP Sensor |
| No. | Name |
|---|---|
| 1 | Wiper Drive Motor Assy |
| 2 | Wiper HP Sensor |
| 3 | Wiper Unit |
| 4 | Head HP Sensor |
| 5 | Head Drive Motor |
